NCB-C6SGRYR-305-24

Norden Cat 6 Shielded Keystone Jack Tool Less 180D are shielded with a two part case giving optimum protection from electromagnetic interference from an outside source. The rear casing is clicked into place after shielded cable has been fed through the centre and terminated to the jack. These Jacks are designed to reduce the Insertion loss & alien cross talk in order to provide maximum flexibility and high performance for all 10G Ethernet applications and are available in a 180° orientation with back interconnection of Dual IDC blocks in universal pin/pair assignment.180° orientation provides perfect termination with minimum distance to the IDC. This is tested to 250 MHz range over 100m and supports T568 A&B wiring & easy installation. The jack is manufactured with an integral cable strain relief. They can be installed into a number of faceplates and unloaded shuttered modules and backward compatible with category 5e/class D system components.

Norden Category 5e Euro module features a slim line design with a shutter to prevent dust from entering the module which is an ideal solution for wall plates and fully supports all presently available LAN applications. This type Euro module provides easy top entry termination, with a clip-on design fitting directly into a euro 50 x 25 aperture for easy installation and is supplied with tie wraps & labeling window. The modules have a dual style IDC punch down block on the termination side which will allow the installer to terminate with either a 110 or Krone insertion tool and is present with colour coding for both T568A & T568B wiring conventions.

Category 6 Connectors exceed Category 6 long lasting high-performance and full support of all present and emerging applications, including 1000BASE-T (Gigabit-Ethernet). High quality overall shield provides excellent EMC (Electro Magnetic Compatibility), minimizing radiation and maximizing noise immunity, ensures long term resistance to corrosion from humidity, extreme temperatures, and airborne contaminants .The range of products includes plugs suitable for round cables with stranded or solid conductors, 24 to 26 AWG and are tested up to 250 MHz over 100 m. These are mainly used for patch-cord termination

Norden Category 6A UTP Tool Less Keystone Jacks are designed to reduce the Insertion loss & alien cross talk in order to provide maximum flexibility and high performance for all 10G Ethernet applications and are available in a 180° orientation with back interconnection of Dual IDC blocks in universal pin/pair assignment.180° orientation provides perfect termination with minimum distance to the IDC. Our tool-less termination allows all eight conductors to be terminated simultaneously when the termination cap is pressed into place .This is tested to 500MHz range over 100m and supports T568 A&B wiring & Easy installation. Stronger & transparent IDC Cover is an added advantage for protection. Norden Category 6A KSJ is also backward compatible supporting current Category 6, Category 5E, and voice network applications.
