LBC3472/00

Bosch LBB 1938/30 Power Amplifier, 480 W power amplifier in a 3U high 19” housing, EN 54‑16 certified, 70 V / 100 V and 8 Ohm outputs, Dual inputs with priority switching, 100 V input for slave operation on 100V speaker line, Frequency response 50 Hz to 20 kHz (+1/‑3 dB @ ‑10 dB ref. rated output), Distortion <1% @ rated output power, 1 kHz, Dimensions (H x W x D) : 145 x 430 x 370 mm.

Bosch LC3-UC06 Ceiling loudspeaker 6W, circular ABS grille and frame, ceiling mounted by 2 integral spring arms, white RAL 9010, 94 dB / 86 dB (SPL) at 6 W power / 1 W (1 kHz, 1 m), 103 dB / 95 dB (SPL) at 6 W power / 1 W (4 kHz, 1 m), Opening angle at 1 kHz / 4kHz (-6 dB) : 180° / 85°.

Bosch MW1-HTX-F5 Microphone with transmitter, 722-746 Hz, UHF wireless handheld microphone transmitter, LCD with battery status and frequency indication, supplied with microphone holder, batteries and storage case, Frequency range: 722-746 MHz, 193 selectable UHF channels.

Bosch MW1-RX-F5 Microphone receiver, 722-746 MHz, UHF wireless microphone receiver, true diversity for stable reception, PLL synthesized technology, supplied with AC/DC adapter with power cord and 1.5 m 3 pin XLR male/ female audio cable, Frequency range: 722-746 MHz, 193 selectable UHF channels.
