NPP-5E1BLKXX1

Norden Cat 6 Shielded Keystone Jack Tool Less 180D are shielded with a two part case giving optimum protection from electromagnetic interference from an outside source. The rear casing is clicked into place after shielded cable has been fed through the centre and terminated to the jack. These Jacks are designed to reduce the Insertion loss & alien cross talk in order to provide maximum flexibility and high performance for all 10G Ethernet applications and are available in a 180° orientation with back interconnection of Dual IDC blocks in universal pin/pair assignment.180° orientation provides perfect termination with minimum distance to the IDC. This is tested to 250 MHz range over 100m and supports T568 A&B wiring & easy installation. The jack is manufactured with an integral cable strain relief. They can be installed into a number of faceplates and unloaded shuttered modules and backward compatible with category 5e/class D system components.

Norden Category 6 UTP punch down keystone Jack gives optimum protection from electromagnetic interference from an outside source. These Jacks are designed to reduce the Insertion loss & alien cross talk in order to provide maximum flexibility and high performance for all 10G Ethernet applications and are available in a 90° orientation with back interconnection of Dual Style IDC blocks in universal pin/pair assignment. 90° orientation provides perfect termination .This is tested to 250 MHz range over 100m and supports T568 A&B wiring & easy installation. The Jack is manufactured with an integral cable strain relief. They can be installed into a number of faceplates and unloaded shuttered modules and backward Compatible with category 5e/class D system components.

Norden Category 6A UTP Tool Less Keystone Jacks are designed to reduce the Insertion loss & alien cross talk in order to provide maximum flexibility and high performance for all 10G Ethernet applications and are available in a 180° orientation with back interconnection of Dual IDC blocks in universal pin/pair assignment.180° orientation provides perfect termination with minimum distance to the IDC. Our tool-less termination allows all eight conductors to be terminated simultaneously when the termination cap is pressed into place .This is tested to 500MHz range over 100m and supports T568 A&B wiring & Easy installation. Stronger & transparent IDC Cover is an added advantage for protection. Norden Category 6A KSJ is also backward compatible supporting current Category 6, Category 5E, and voice network applications.

Norden brushed stainless steel faceplates allow mounting any two combination of keystone Jacks or blank or Euro module. Stainless steel faceplates are ideal for use in environments that require greater durability and a sanitary, easy-to-clean solution. This face plate is ideal for space limited areas or desk-top trunking where a fixed number of ports are to be installed and modularity is not required.
